Trinity Episcopal ChurchSt. Louis, Missouri

Opus 65 : 2 manuals, 23 ranks

year complete, 2009

Electro-pneumatic slider instrument. Completion April 2009.
STANDARD FEATURES:

1. Quimby Pipe Organs electro-pneumatic slider windchests based on the Blackinton design for all ranks that are not extended. Construction style assures reliable operation without the use of slider seals. Electro-pneumatic pouch windchests for all reed ranks with Primaries for all reed pipes, extended ranks, and pedal ranks.

2. Two-manual drawknob console with naturals covered in synthetic plastic like used on Steinway pianos, and sharps in ebony, pedal sharps of rosewood. Manuals, drawknob units, coupler units, and swell shoes by Harris Precision Products. Adjustable bench with crank height mechanism.

3. Peterson ICS 4000 control system for all key and stop functions.

4. Peterson ICS 4000, 99 level combination action and piston sequencer.

5. Swell shade 2″ thick laminate sugar pine construction with pivots on ball bearings.

Read or download the feature article (includes tonal spec)
TrinityEpiscopal_2010-TAO-Feature
